Spinel -- Ruby AOT Compiler

Spinel compiles Ruby source code into standalone native executables. It performs whole-program type inference and generates optimized C code, achieving significant speedups over CRuby.

Spinel is self-hosting: the compiler backend is written in Ruby and compiles itself into a native binary.

How It Works

Ruby (.rb)
    |
    v
spinel_parse           Parse with Prism (libprism), serialize AST
    |                  (C binary, or CRuby + Prism gem as fallback)
    v
AST text file
    |
    v
spinel_codegen         Type inference + C code generation
    |                  (self-hosted native binary)
    v
C source (.c)
    |
    v
cc -O2 -Ilib -lm      Standard C compiler + runtime header
    |
    v
Native binary           Standalone, no runtime dependencies

Quick Start

Fetch libprism sources (from the prism gem on rubygems.org):

make deps

Build everything:

make

Write a Ruby program:

cat > hello.rb <<'RUBY' def fib(n) if n < 2 n else fib(n - 1) + fib(n - 2) end end puts fib(34) RUBY

Compile and run:

./spinel hello.rb ./hello # prints 5702887 (instantly)

Options

./spinel app.rb # compiles to ./app ./spinel app.rb -o myapp # compiles to ./myapp ./spinel app.rb -c # generates app.c only ./spinel app.rb -S # prints C to stdout

Self-Hosting

Spinel compiles its own backend. The bootstrap chain:

CRuby + spinel_parse.rb → AST
CRuby + spinel_codegen.rb → gen1.c → bin1
bin1 + AST → gen2.c → bin2
bin2 + AST → gen3.c
gen2.c == gen3.c   (bootstrap loop closed)

Benchmarks

74 tests pass. 55 benchmarks pass. Geometric mean: ~11.6x faster than miniruby (Ruby 4.1.0dev) across the 28 benchmarks below. Baseline is the latest CRuby miniruby build (without bundled gems), which is considerably faster than the system ruby (3.2.3); Spinel's advantage is correspondingly smaller but still substantial on computation-heavy workloads.

Computation

Benchmark

Spinel

miniruby

Speedup

life (Conway's GoL)

20 ms

1,733 ms

86.7x

ackermann

5 ms

374 ms

74.8x

mandelbrot

25 ms

1,453 ms

58.1x

fib (recursive)

17 ms

581 ms

34.2x

nqueens

10 ms

304 ms

30.4x

tarai

16 ms

461 ms

28.8x

tak

22 ms

532 ms

24.2x

matmul

13 ms

313 ms

24.1x

sudoku

6 ms

102 ms

17.0x

partial_sums

93 ms

1,498 ms

16.1x

fannkuch

2 ms

19 ms

9.5x

sieve

39 ms

332 ms

8.5x

fasta (DNA seq gen)

3 ms

21 ms

7.0x

Data Structures & GC

Benchmark

Spinel

miniruby

Speedup

rbtree (red-black tree)

24 ms

543 ms

22.6x

splay tree

14 ms

195 ms

13.9x

huffman (encoding)

6 ms

59 ms

9.8x

so_lists

76 ms

410 ms

5.4x

binary_trees

11 ms

40 ms

3.6x

linked_list

136 ms

388 ms

2.9x

gcbench

1,845 ms

3,641 ms

2.0x

Real-World Programs

Benchmark

Spinel

miniruby

Speedup

json_parse

39 ms

394 ms

10.1x

bigint_fib (1000 digits)

2 ms

16 ms

8.0x

ao_render (ray tracer)

417 ms

3,334 ms

8.0x

pidigits (bigint)

2 ms

13 ms

6.5x

str_concat

2 ms

13 ms

6.5x

template engine

152 ms

936 ms

6.2x

csv_process

234 ms

860 ms

3.7x

io_wordcount

33 ms

97 ms

2.9x

Supported Ruby Features

Core: Classes, inheritance, super, include (mixin), attr_accessor, Struct.new, alias, module constants, open classes for built-in types.

Control Flow: if/elsif/else, unless, case/when, case/in (pattern matching), while, until, loop, for..in (range and array), break, next, return, catch/throw, &. (safe navigation).

Blocks: yield, block_given?, &block, proc {}, Proc.new, lambda -> x { }, method(:name). Block methods: each, each_with_index, map, select, reject, reduce, sort_by, any?, all?, none?, times, upto, downto.

Exceptions: begin/rescue/ensure/retry, raise, custom exception classes.

Types: Integer, Float, String (immutable + mutable), Array, Hash, Range, Time, StringIO, File, Regexp, Bigint (auto-promoted), Fiber. Polymorphic values via tagged unions. Nullable object types (T?) for self-referential data structures (linked lists, trees).

Global Variables: $name compiled to static C variables with type-mismatch detection at compile time.

Strings: << automatically promotes to mutable strings (sp_String) for O(n) in-place append. +, interpolation, tr, ljust/rjust/center, and all standard methods work on both. Character comparisons like s[i] == "c" are optimized to direct char array access (zero allocation). Chained concatenation (a + b + c + d) collapses to a single malloc via sp_str_concat4 / sp_str_concat_arr -- N-1 fewer allocations. Loop-local str.split(sep) reuses the same sp_StrArray across iterations (csv_process: 4 M allocations eliminated).

Regexp: Built-in NFA regexp engine (no external dependency). =~, $1-$9, match?, gsub(/re/, str), sub(/re/, str), scan(/re/), split(/re/).

Bigint: Arbitrary precision integers via mruby-bigint. Auto-promoted from loop multiplication patterns (e.g. q = q * k). Linked as static library -- only included when used.

Fiber: Cooperative concurrency via ucontext_t. Fiber.new, Fiber#resume, Fiber.yield with value passing. Captures free variables via heap-promoted cells.

Memory: Mark-and-sweep GC with size-segregated free lists, non-recursive marking, and sticky mark bits. Small classes (≤8 scalar fields, no inheritance, no mutation through parameters) are automatically stack-allocated as value types -- 1M allocations of a 5-field class drop from 85 ms to 2 ms. Programs using only value types emit no GC runtime at all.

Symbols: Separate sp_sym type, distinct from strings (:a != "a"). Symbol literals are interned at compile time (SPS_name constants); String#to_sym uses a dynamic pool only when needed. Symbol-keyed hashes ({a: 1}) use a dedicated sp_SymIntHash that stores sp_sym (integer) keys directly rather than strings -- no strcmp, no dynamic string allocation.

I/O: puts, print, printf, p, gets, ARGV, ENV[], File.read/write/open (with blocks), system(), backtick.

Optimizations

Whole-program type inference drives several compile-time optimizations:

• Value-type promotion: small immutable classes (≤8 scalar fields) become C structs on the stack, eliminating GC overhead entirely.
• Constant propagation: simple literal constants (N = 100) are inlined at use sites instead of going through cst_N runtime lookup.
• Loop-invariant length hoisting: while i < arr.length evaluates arr.length once before the loop; while i < str.length hoists strlen. Mutation of the receiver inside the body (e.g. arr.push) correctly disables the hoist.
• Method inlining: short methods (≤3 statements, non-recursive) get static inline so gcc can inline them at call sites.
• String concat chain flattening: a + b + c + d compiles to a single sp_str_concat4 / sp_str_concat_arr call -- one malloc instead of N-1 intermediate strings.
• Bigint auto-promotion: loops with x = x * y or fibonacci-style c = a + b self-referential addition auto-promote to bigint.
• Bigint to_s: divide-and-conquer O(n log²n) via mruby-bigint's mpz_get_str instead of naive O(n²).
• Static symbol interning: "literal".to_sym resolves to a compile-time SPS_<name> constant; the runtime dynamic pool is only emitted when dynamic interning is actually used.
• strlen caching in sub_range: when a string's length is hoisted, str[i] accesses use sp_str_sub_range_len to skip the internal strlen call.
• split reuse: fields = line.split(",") inside a loop reuses the existing sp_StrArray rather than allocating a new one.
• Dead-code elimination: compiled with -ffunction-sections -fdata-sections and linked with --gc-sections; each unused runtime function is stripped from the final binary.
• Iterative inference early exit: the param/return/ivar fixed-point loop stops as soon as a signature of the three refined arrays stops changing. Most programs converge in 1-2 iterations instead of the full 4, cutting bootstrap time by ~14%.
• parse_id_list byte walk: the AST-field list parser (called ~120 K times during self-compile) walks bytes manually via s.bytes[i] instead of s.split(","), dropping N+1 allocations per call to 2.
• Warning-free build: generated C compiles cleanly at the default warning level across every test and benchmark; the harness uses -Werror so regressions surface immediately.

Architecture

spinel                One-command wrapper script (POSIX shell)
spinel_parse.c        C frontend: libprism → text AST (1,061 lines)
spinel_codegen.rb     Compiler backend: AST → C code (21,109 lines)
lib/sp_runtime.h      Runtime library header (581 lines)
lib/sp_bigint.c       Arbitrary precision integers (5,394 lines)
lib/regexp/           Built-in regexp engine (1,759 lines)
test/                 74 feature tests
benchmark/            55 benchmarks
Makefile              Build automation

The compiler backend (spinel_codegen.rb) is written in a Ruby subset that Spinel itself can compile: classes, def, attr_accessor, if/case/while, each/map/select, yield, begin/rescue, String/Array/Hash operations, File I/O.

No metaprogramming, no eval, no require in the backend.

The runtime (lib/sp_runtime.h) contains GC, array/hash/string implementations, and all runtime support as a single header file. Generated C includes this header, and the linker pulls only the needed parts from libspinel_rt.a (bigint + regexp engine).

The parser has two implementations:

• spinel_parse.c links libprism directly (no CRuby needed)
• spinel_parse.rb uses the Prism gem (CRuby fallback)

Both produce identical AST output. The spinel wrapper prefers the C binary if available. require_relative is resolved at parse time by inlining the referenced file.

Building

make deps # fetch libprism into vendor/prism (one-time) make # build parser + regexp library + bootstrap compiler make test # run 74 feature tests (requires bootstrap) make bench # run 55 benchmarks (requires bootstrap) make bootstrap # rebuild compiler from source sudo make install # install to /usr/local (spinel in PATH) make clean # remove build artifacts

Override install prefix: make install PREFIX=$HOME/.local

Prism is the Ruby parser used by spinel_parse. make deps downloads the prism gem tarball from rubygems.org and extracts its C sources to vendor/prism. If you already have the prism gem installed, the build auto-detects it; you can also point at a custom location with PRISM_DIR=/path/to/prism.

CRuby is needed only for the initial bootstrap. After make, the entire pipeline runs without Ruby.

Limitations

• No eval: eval, instance_eval, class_eval
• No metaprogramming: send, method_missing, define_method (dynamic)
• No threads: Thread, Mutex (Fiber is supported)
• No encoding: assumes UTF-8/ASCII
• No general lambda calculus: deeply nested -> x { } with [] calls

Dependencies

• Build time: libprism (C library), CRuby (bootstrap only)
• Run time: None. Generated binaries need only libc + libm.
• Regexp: Built-in engine, no external library needed.
• Bigint: Built-in (from mruby-bigint), linked only when used.

History

Spinel was originally implemented in C (18K lines, branch c-version), then rewritten in Ruby (branch ruby-v1), and finally rewritten in a self-hosting Ruby subset (current master).

License

MIT License. See LICENSE.
