TinyOS — Ultra-Lightweight RTOS for IoT

An ultra-lightweight real-time operating system for resource-constrained IoT and embedded devices.
Kernel footprint under 10 KB, 2 KB minimum RAM, preemptive priority-based scheduling.

Features

Supported Hardware

Architecture

Examples

ARM Cortex-M (M0/M0+/M3/M4/M7)

STM32, nRF52, Raspberry Pi Pico

RISC-V (RV32I)

ESP32-C3

AVR (experimental)

ATmega

Quick Start

Prerequisites: gcc-arm-none-eabi

make example-blink # LED blink make example-shell # Interactive shell over UART make example-mqtt # MQTT publish/subscribe make example-iot # Multi-sensor IoT node make size # Binary size report

Minimal task example:

#include "tinyos.h"

void my_task(void *param) { while (1) { /* work */ os_task_delay_ms(100); } }

int main(void) { tcb_t task; os_init(); os_task_create(&task, "my_task", my_task, NULL, PRIORITY_NORMAL); os_start(); }

API Overview

Task Management

os_task_create(tcb, name, entry, param, priority) os_task_delete(task) os_task_suspend(task) / os_task_resume(task) os_task_delay(ticks) / os_task_delay_ms(ms) os_task_set_priority(task, priority) os_task_get_stats(task, stats) os_task_get_stats_by_index(index, stats) /* iterate all tasks by index */ os_task_find_by_name(name) /* returns tcb_t*, NULL if not found */ os_get_system_stats(stats) os_get_memory_stats(&free, &used, &allocs, &frees)

Synchronization

os_mutex_init(mutex) / os_mutex_lock(mutex, timeout) / os_mutex_unlock(mutex) os_semaphore_init(sem, count) / os_semaphore_wait(sem, timeout) / os_semaphore_post(sem) os_cond_init(cond) / os_cond_wait(cond, mutex, timeout) os_cond_signal(cond) / os_cond_broadcast(cond) os_event_group_set_bits(eg, bits) / os_event_group_wait_bits(eg, bits, opts, out, timeout) os_queue_init(q, buf, item_size, max) / os_queue_send(q, item, timeout) os_queue_receive(q, item, timeout) / os_queue_peek(q, item, timeout)

Timers

os_timer_create(timer, name, type, period_ms, callback, param) os_timer_start(timer) / os_timer_stop(timer) / os_timer_reset(timer) os_timer_change_period(timer, ms) / os_timer_get_remaining_ms(timer)

Shell

/* Register custom commands before calling shell_start() */ shell_register_cmd(name, handler_fn, help_text)

/* Provide UART I/O callbacks and start the shell task */ shell_io_t io = { .getc = uart_getc, .puts = uart_puts }; shell_start(&io)

/* Change the prompt at any time */ shell_set_prompt("mydevice> ")

/* Execute a single line programmatically */ shell_exec(line)

Custom command example:

static int cmd_led(int argc, char *argv[]) { if (argc < 2) return 1; /* non-zero → prints usage */ bool on = (strcmp(argv[1], "on") == 0); gpio_write(LED_PIN, on); return 0; }

/* In main(), before shell_start(): */ shell_register_cmd("led", cmd_led, "led <on|off> Toggle LED");

Built-in Shell Commands

Command

Description

help [cmd]

List all commands, or show detailed help for cmd

clear

Clear the terminal screen (VT100)

echo <text>

Print text to the terminal

history

Show command history

ps

List all tasks (state, priority, CPU%, stack usage)

top

Task list sorted by CPU usage, descending

kill <name> [suspend|resume|delete]

Control a task by name

mem

Heap statistics (total / used / free, alloc/free counts)

ver

TinyOS version and formatted uptime

net

Network statistics (Ethernet, IP, UDP, TCP counters)

ping <ip> [count]

Send ICMP echo requests

ifconfig [ip|netmask|gw|dns <addr>]

Show or change network configuration

power [active|idle|sleep|deepsleep]

Power stats or mode change

ls [path]

List directory (default: /)

cat <file>

Display file contents

mkdir <path>

Create directory

rm <path>

Remove file or empty directory

df

Filesystem usage statistics

reboot

Reboot the system

Line editor key bindings:

Key

Action

← / Ctrl-B

Move cursor left

→ / Ctrl-F

Move cursor right

Home / Ctrl-A

Jump to start of line

End / Ctrl-E

Jump to end of line

↑ / ↓

Navigate command history

Tab

Complete command name

Ctrl-K

Kill to end of line

Ctrl-U

Kill to start of line

Ctrl-W

Kill previous word

Ctrl-L

Clear screen and redraw

Ctrl-C

Cancel current line

Shell configuration (include/tinyos/shell.h):

#define SHELL_MAX_COMMANDS 32 /* max registered commands */ #define SHELL_LINE_MAX 128 /* max input line length (bytes) */ #define SHELL_ARGV_MAX 16 /* max arguments per command */ #define SHELL_HISTORY_DEPTH 8 /* command history entries */

Network

net_init(driver, config) / net_start() net_socket(type) / net_bind(sock, addr) / net_connect(sock, addr, timeout_ms) net_send(sock, data, len, timeout_ms) / net_recv(sock, buf, len, timeout_ms) net_sendto(sock, data, len, addr) / net_recvfrom(sock, buf, len, addr) net_close(sock) net_ping(dest_ip, timeout_ms, rtt) net_dns_resolve(hostname, ip, timeout_ms) net_http_get(url, response, timeout_ms) net_http_post(url, content_type, body, len, response, timeout_ms)

TLS / DTLS

TLS 1.2/1.3 over TCP and DTLS 1.2 over UDP backed by mbedTLS.
Enable at build time with -DTINYOS_TLS_ENABLE and link against mbedTLS.

/* Client (TLS over TCP) */ tls_context_t tls; tls_config_t cfg = TLS_CONFIG_DEFAULT_CLIENT; cfg.ca_cert = ca_cert_pem; cfg.ca_cert_len = sizeof(ca_cert_pem); tls_init(&tls, &cfg);

net_socket_t sock = net_socket(SOCK_STREAM); net_connect(sock, &broker_addr, 5000); tls_connect(&tls, sock, "example.com", 5000);

tls_send(&tls, data, len); tls_recv(&tls, buf, sizeof(buf), 5000); tls_close(&tls);

/* Server (TLS accept) */ tls_config_t srv_cfg = TLS_CONFIG_DEFAULT_SERVER; srv_cfg.cert = server_cert_pem; srv_cfg.cert_len = sizeof(server_cert_pem); srv_cfg.key = server_key_pem; srv_cfg.key_len = sizeof(server_key_pem); tls_init(&tls, &srv_cfg); tls_accept(&tls, client_sock, 5000);

/* DTLS over UDP */ tls_config_t dtls_cfg = TLS_CONFIG_DEFAULT_DTLS_CLIENT; net_socket_t usock = net_socket(SOCK_DGRAM); tls_connect_dtls(&tls, usock, "example.com", 5000);

MQTT

Full MQTT 3.1.1 with per-message QoS delivery guarantees.

mqtt_config_t cfg = { .broker_host = "mqtt.example.com", .client_id = "tinyos-01", .keepalive_sec = 60, .clean_session = true, .auto_reconnect = true, .reconnect_interval_ms = 3000, /* base; doubles each attempt (max 60 s) */ }; mqtt_client_t client; mqtt_client_init(&client, &cfg); mqtt_set_connection_callback(&client, on_connect, NULL); mqtt_set_message_callback(&client, on_message, NULL); mqtt_connect(&client);

/* Publish — QoS1/2 are buffered offline if disconnected */ mqtt_publish(&client, "sensors/temp", "23.5", 4, MQTT_QOS_1, false);

/* Inspect reliability queues */ uint8_t in_flight = mqtt_get_inflight_count(&client); /* sent, awaiting ACK */ uint8_t pending = mqtt_get_pending_count(&client); /* queued while offline */

mqtt_subscribe(&client, "cmd/#", MQTT_QOS_1); mqtt_flush_pending(&client); /* discard offline queue */ mqtt_disconnect(&client);

MQTT Reliability Model

QoS 0  ─── fire-and-forget; dropped if disconnected
QoS 1  ─── in-flight table tracks each PUBLISH until PUBACK
              ↳ retransmits with DUP=1 every 5 s, up to 5 times
              ↳ if offline → offline queue (up to 8 messages)
QoS 2  ─── full PUBLISH → PUBREC → PUBREL → PUBCOMP handshake
              ↳ each step is retried independently on timeout

Auto-reconnect back-off: 3 s → 6 s → 12 s → … → 60 s (cap)
On reconnect: re-subscribes all topics, flushes offline queue

MQTT reliability configuration (include/tinyos/mqtt.h):

#define MQTT_MAX_INFLIGHT 8 /* in-flight slots */ #define MQTT_MAX_PENDING 8 /* offline queue slots */ #define MQTT_MAX_PAYLOAD_SIZE 512 /* bytes per queued msg */ #define MQTT_RETRY_INTERVAL_MS 5000 /* retry after (ms) */ #define MQTT_MAX_RETRY_COUNT 5 /* retries before drop */ #define MQTT_RECONNECT_BASE_MS 3000 /* first reconnect delay */ #define MQTT_RECONNECT_MAX_MS 60000 /* backoff ceiling */

CoAP

coap_init(ctx, config, is_server) / coap_start(ctx) / coap_stop(ctx) coap_get(ctx, ip, port, path, response, timeout_ms) coap_post(ctx, ip, port, path, format, payload, len, response, timeout_ms) coap_resource_create(ctx, path, handler, user_data) coap_process(ctx, timeout_ms)

OTA

ota_init(config) ota_start_update(url, callback, user_data) ota_write_chunk(data, size, offset) / ota_finalize_update() ota_confirm_boot() / ota_rollback() ota_verify_partition(type)

File System

fs_format(device) / fs_mount(device) / fs_unmount() fs_open(path, flags) / fs_close(fd) fs_read(fd, buf, size) / fs_write(fd, buf, size) fs_seek(fd, offset, whence) / fs_tell(fd) fs_mkdir(path) / fs_remove(path) / fs_rmdir(path) fs_stat(path, stat) fs_opendir(path) / fs_readdir(dir, entry) / fs_closedir(dir) fs_get_stats(stats) / fs_get_free_space() / fs_is_mounted()

Power Management

os_power_init() os_power_set_mode(mode) /* ACTIVE / IDLE / SLEEP / DEEP_SLEEP */ os_power_get_mode() os_power_enter_sleep(duration_ms) os_power_enter_deep_sleep(duration_ms) os_power_enable_tickless_idle(enable) os_power_set_cpu_frequency(freq_hz) os_power_configure_wakeup(source, enable) os_power_get_stats(stats) os_power_get_consumption_mw() os_power_estimate_battery_life_hours()

Watchdog

wdt_init(config) / wdt_start() / wdt_stop() wdt_feed() / wdt_set_timeout(ms) wdt_register_task(task, timeout_ms) / wdt_feed_task(task)

Configuration

include/tinyos.h — kernel and OS:

#define MAX_TASKS 8 /* max concurrent tasks */ #define STACK_SIZE 256 /* stack size per task (words) */ #define TICK_RATE_HZ 1000 /* scheduler tick frequency (Hz) */ #define TIME_SLICE_MS 10 /* round-robin time slice (ms) */

include/tinyos/shell.h — interactive shell:

include/tinyos/mqtt.h — MQTT reliability:

#define MQTT_MAX_INFLIGHT 8 /* in-flight QoS1/2 slots */ #define MQTT_MAX_PENDING 8 /* offline queue slots */ #define MQTT_MAX_PAYLOAD_SIZE 512 /* max queued payload bytes */ #define MQTT_RETRY_INTERVAL_MS 5000 /* unACKed retry interval */ #define MQTT_MAX_RETRY_COUNT 5 /* retries before discard */ #define MQTT_RECONNECT_BASE_MS 3000 /* initial reconnect delay */ #define MQTT_RECONNECT_MAX_MS 60000 /* back-off ceiling */

TLS — requires mbedTLS; enable with:

CFLAGS += -DTINYOS_TLS_ENABLE LDFLAGS += -lmbedtls -lmbedcrypto -lmbedx509

Project Structure

tinyos-rtos/
├── include/
│   ├── tinyos.h              # Core API (tasks, sync, timers, memory, FS, power)
│   └── tinyos/
│       ├── shell.h           # Interactive shell API & configuration
│       ├── net.h             # Network stack
│       ├── tls.h             # TLS 1.2/1.3 + DTLS 1.2 (mbedTLS)
│       ├── mqtt.h            # MQTT 3.1.1 client
│       ├── coap.h            # CoAP RFC 7252
│       ├── ota.h             # OTA firmware updates
│       └── watchdog.h        # Watchdog timer
├── src/
│   ├── kernel.c              # Preemptive scheduler & task management
│   ├── sync.c                # Mutex, semaphore, queue, condition var, event groups
│   ├── timer.c               # Software timers
│   ├── memory.c              # Heap allocator
│   ├── shell.c               # Interactive shell (VT100, history, tab completion)
│   ├── filesystem.c          # Block-device file system
│   ├── security.c            # MPU memory protection
│   ├── power.c               # Power management & CPU frequency scaling
│   ├── watchdog.c            # Watchdog (HW + SW, per-task monitoring)
│   ├── bootloader.c          # Secure bootloader
│   ├── ota.c                 # OTA A/B partition updates
│   ├── mqtt.c                # MQTT client (in-flight table, offline queue)
│   ├── coap.c                # CoAP client/server
│   └── net/
│       ├── network.c         # Core & buffer management
│       ├── ethernet.c        # Ethernet / ARP
│       ├── ip.c              # IPv4 / ICMP
│       ├── socket.c          # UDP / TCP socket API
│       ├── http_dns.c        # HTTP client & DNS resolver
│       └── tls.c             # TLS/DTLS (mbedTLS wrapper)
├── drivers/
│   ├── flash.c / flash.h     # Flash memory driver
│   ├── ramdisk.c / ramdisk.h # RAM disk (testing)
│   └── loopback_net.c        # Loopback network driver (testing)
└── examples/
    ├── blink_led.c           # GPIO blink
    ├── iot_sensor.c          # Multi-task sensor node
    ├── shell_demo.c          # Custom shell commands over UART
    ├── network_demo.c        # TCP/UDP/HTTP/ping
    ├── tls_demo.c            # TLS client/server
    ├── mqtt_demo.c           # MQTT publish/subscribe (QoS 1/2)
    ├── coap_demo.c           # CoAP client/server
    ├── ota_demo.c            # Firmware update flow
    ├── filesystem_demo.c     # File I/O
    ├── watchdog_demo.c       # Watchdog configuration
    ├── low_power.c           # Power mode transitions
    ├── software_timers.c     # Timer creation and callbacks
    ├── event_groups.c        # Event synchronisation
    ├── condition_variable.c  # Producer/consumer
    ├── priority_adjustment.c # Dynamic priority
    └── task_statistics.c     # CPU and stack monitoring

Performance

Component

ROM

RAM

Kernel

6 KB

512 B

Per task

—

~1 KB

Mutex

—

12 B

Semaphore

—

8 B

Message queue (10 items)

—

40 B + data

Shell (with 19 built-ins)

~4 KB

~2.5 KB

MQTT client (with queues)

~8 KB

~10 KB

Architecture

Context switch

Cortex-M0

~2 μs

Cortex-M4

~1 μs

RISC-V

~1.5 μs

System requirements: 2 KB RAM minimum · < 10 KB ROM for kernel alone

License

MIT License — see LICENSE for details.
